EVA Select Complete System, Eva Select Digital Sensor #2, Evasoft Software and Positioners ImageWorks 9992413200

EVA Select Digital Sensor:

• ImageWorks' EVA Select digital sensors leverage CMOS technology to provide high resolution, diagnostic-quality images with wide latitude, sharp clarity and enhanced contrast. Whether you are converting to digital for the first time, or expanding your existing capabilities.
• The ImageWorks EVA Select Digital Sensor System has been completely redesigned for quality and performance.
• Sensor Attributes:
  • Durable CMOS technology provides superior images using only a fraction of the power required by other digital sensor technologies.
  • Works with all major imaging software.
  • Impact-resistant housings are designed to minimize damage and wear from a biting patient.
  • Fantastic resolution: 20+ lp/mm.
  • Sensor comes in adult size (size 2) and pedo size (size 1).
  • Rounded corners for comfort.
  • Hot swapping sensors between multiple computers offers greater speed, convenience and value.
  • Service multiple operatories with one sensor using the docking station.
  • Small, inexpensive docking stations fit in the palm of your hand and make expansion easy.
  • Razor thin: aprox. 5 mm thick
  • Two-year limited warranty for peace of mind
• Reliable:
  • The reliability of EVA Select sensors is backed by hundreds of installations ranging from single chair clinics to large dental chains. EVA Select offers a comfortable sensor design coupled with a high standard of technology.
• Functional:
  • Just a few millimetres thin, EVA Select sensors deliver crisp, clear radiographs with virtually any intraoral x-ray head. The CMOS imaging chip is designed for maximum durability. Fast USB connectivity delivers images to a computer monitor in seconds.
• Value:
  • EVA Select's value makes it an ideal choice for both large dental chains and value-conscious single practices.
• The EVA Select System:
  • The EVA Select sensor with software that works with your existing system and practice management software.
  • Imaging software that's easy to use.
  • Powerful diagnostic enhancement tools.
  • Works with all major practice management platforms.
• Market-leading resolution (20+ line pairs per mm).
• Integrates with major software platforms.
• USB inter face works with your existing system.
• EvaSoft Imaging software integrates all of images into one system.
• Easy and intuitive to use. No training needed. No mistakes.
• Has capability to work with all major practice management platforms.
• Powerful diagnostic capabilities.
• One-click insurance claims allows you to work faster.
• Technical Specification(Size 2):
  • Gray Shades - 4096(12bites)
  • Imager Resolution - 20+ lp/mm
  • Optical Resolution - 26 lp/mm
  • Pixel Size - 19 microns × 19 microns.
  • Active Area - 36mm(l) × 25.99mm(w)
  • Capsule Dimension - 42.8mm(l) × 30.5mm(w) × 5.4mm(Th)
  • Image Size - 4.94 MB

Application:

• EVA Select Complete System Eva Select Digital Sensor Provides high-quality of X-rays.
