Elcomed SA-310 Motor with 3.5 m Cable W&H 15933103
Item Number: | 15933103 |
Packaging: | ea |
Manufacturer: | W&H Group |
Item Discontinued.
Features & Benefits:
- Elcomed is the Number 1 in the operating theatre, In addition to the expert knowledge of the surgeon, the drive unit is also a pivotal factor in the success of a surgical procedure.
- Just one operating stage for setting all necessary parameters.
- The six most important recurring operational procedures can be saved as individual programmes.
- All information in one user level.
- Complete documentation via USB flash drive.
- Shortest and lightest motor with 50,000 rpm.
- Up to 80 Ncm on the rotary instrument.
- 6 Programs with individually adjustable parameter.
- Automatic thread cutter function.
- Motor with cable, thermo washer disinfectable and sterilizable.
- One display, Thousands of Possibilities:
- Elcomed makes complicated processes as simple as possible.
- All necessary parameters can be set very easily using just one operating stage.
- In addition to revolutions per minute and torque, the supply of liquid can also easily be adjusted during use.
- Six programs for the most frequent recurring operational procedures can be saved at the first start-up.
- An Amazing Motor:
- Shortest and lightest motor with 50,000 revolutions per minute.
- Can be used with all instruments that have an ISO connection.
- Complete Documentation:
- If desired, the Elcomed can document every step in the application. The data is accessible at any time.
- The data are saved as bitmap and csv file on the USB flash drive included in the delivery, ready to be imported into standard analysis programs.
- In this way, they can easily be accessed at any time and at no additional cost.
- Convenient Foot control S-N1:
- With program switching, activation and deactivation of the coolant pump, clockwise / anticlockwise rotation, On-Off function and infinitely variable speed control of the motor up to the preselected maximum speed.
- The multifunctional foot control allows sterile working and optimum freedom for your hands.
- Automatic Thread Cutter Function:
- The automatic thread cutter function for thread cuts.
- Minimizes the compression of the bone and therefore promotes stress-free healing of the implant.
- Prevents excessive bone compression while screwing in the implant.
- Elcomed SA-310 Motor without documentation Technical data:
- Max. torque at the rotary instrument: 80 Ncm.
- Documentation: No.
- Mains voltage: 100 - 130 V or 220 - 240 V, 50 / 60 Hz.
- Max. mechanical output power: 100 W.
- Max. torque at the motor: 7 Ncm.
- Motor speed range in the nominal voltage: 300 min-1 - max. 50,000 min-1, safety stop at 40,000 min-1.
- Intended transmission instruments: ISO connection 3964 (DIN 13.940).
- Length of motor cable: 3.5 m.
- Coolant flow rate at 100 %: At least 90 ml/min.
- Foot control: Yes.
- Height / Width / Depth: 109 x 256 x 305 mm.
- Elcomed Without Documentation Function consists of
- Control Unit
- Foot Control S-N1
- Motor with 3.5 Cable and Clips
- Irrigation Tubing Set
- Mains Cable
- Motor Support
- Stand
- Locking Pins
Application:
- Elcomed from W&H is a high-quality innovative solution for maxillofacial surgery, dental surgery and implantology.
